Mild Steel 6011 Welding Electrodes 10lb box

Mild Steel 6011 Welding Electrodes 10lb box

by INWELD
Save $21.00 Save $20.00
$75.00
$75.00 - $75.00
$75.00
$55.00
$54.00 - $55.00
$55.00
SKU we6011093

⚠️WARNING: Cancer and Reproductive Harm

www.p65warnings.ca.gov

Fusion Flow MADE IN USA

Inweld 6011
AWS A5.1 E6011
Chemical Composition of Inweld 6011

Fe            C      Cr     Ni     Mo     Mn    Si    P    S      V     Cu

Balance 0.20  0.20  0.30  0.30  1.20  1.00  ---  ---  0.08  ---

Single values are maximum unless otherwise specified.

Description and Applications

All-Position, Multiple-Pass Mild Steel Electrode with a strong arc force and fast solidification of weld metal. Designed to provide the deepest penetrating welds while using small AC welding machines as well as DC types. High Deposition efficiency and non-porous welds even over rusty or oily steel or where there is a problem of poor groove fit-up. Great electrode to use with minimal preparation. Common uses include: many general structures such as car and truck frames, farm implements, tractors, trailer frames, storage tanks, and galvanized steel.

Typical Weld Metal Properties

                              AWS Spec

Tensile Strength:   60,000 psi

Yield Strength:      48,000 psi

Elongation:            22%



Recommended Parameters

SMAW (DCEP – Electrode+)

Wire Diameter     Flat Amperage     Vertical & Overhead amps

3/32”                       50-80                            40-70

1/8”                         70-110                          60-100

5/32”                       110-160                        90-140

Fusion Flow MADE IN USA

Inweld 6011
AWS A5.1 E6011
Chemical Composition of Inweld 6011

Fe            C      Cr     Ni     Mo     Mn    Si    P    S      V     Cu

Balance 0.20  0.20  0.30  0.30  1.20  1.00  ---  ---  0.08  ---

Single values are maximum unless otherwise specified.

Description and Applications

All-Position, Multiple-Pass Mild Steel Electrode with a strong arc force and fast solidification of weld metal. Designed to provide the deepest penetrating welds while using small AC welding machines as well as DC types. High Deposition efficiency and non-porous welds even over rusty or oily steel or where there is a problem of poor groove fit-up. Great electrode to use with minimal preparation. Common uses include: many general structures such as car and truck frames, farm implements, tractors, trailer frames, storage tanks, and galvanized steel.

Typical Weld Metal Properties

                              AWS Spec

Tensile Strength:   60,000 psi

Yield Strength:      48,000 psi

Elongation:            22%



Recommended Parameters

SMAW (DCEP – Electrode+)

Wire Diameter     Flat Amperage     Vertical & Overhead amps

3/32”                       50-80                            40-70

1/8”                         70-110                          60-100

5/32”                       110-160                        90-140

Customer Reviews

Based on 18 reviews
83%
(15)
17%
(3)
0%
(0)
0%
(0)
0%
(0)
100.0
100.0
B
Brian clyde
Durable

These electrodes are incredibly durable. I've put them through some tough welding jobs, and they hold up exceptionally well. I can count on them to withstand the demands of my projects without fail.

M
Michael Ferrerio
Great Value

These electrodes offer unbeatable value. Not only are they affordable, but they also deliver exceptional performance. Whether you're a hobbyist or a professional welder, you can't go wrong with these.

D
Donald Moyer
Easy to Use

As a beginner welder, I appreciate how easy these electrodes are to use. They strike effortlessly and provide excellent control. They've helped me improve my skills significantly.

J
Jose Kercado
Consistent Quality

One thing I love about these electrodes is the consistent quality. Every batch performs just as well as the last, ensuring that I can rely on them for consistent welds time and time again.

W
Woody
Great Quality

These welding electrodes are top-notch! The quality is outstanding, and they perform exceptionally well. I've been using them for a while now and couldn't be happier with the results. Highly recommended.
